Fujitsu ASYG09KMCDN Design & Technical Manual

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG09KMCDN
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 2.91 1.55 2.84 1.58 2.77 1.62 2.70 1.65 2.63 1.68
-20 -21 3.24 1.66 3.16 1.70 3.09 1.73 3.01 1.77 2.93 1.80
-15 -16 3.57 1.77 3.49 1.81 3.40 1.85 3.32 1.88 3.23 1.92
-10 -11 4.12 1.86 4.02 1.90 3.92 1.94 3.82 1.98 3.73 2.02
-5 -7 4.67 1.95 4.56 1.99 4.45 2.04 4.33 2.08 4.22 2.12
0 -2 5.22 2.04 5.09 2.09 4.97 2.13 4.84 2.17 4.72 2.21
5 3 5.77 2.13 5.63 2.18 5.49 2.22 5.35 2.27 5.22 2.31
7 6 5.99 2.17 5.84 2.21 5.70 2.26 5.56 2.31 5.42 2.35
10 8 6.09 2.16 5.95 2.21 5.80 2.25 5.66 2.30 5.51 2.34
15 10 5.91 2.06 5.77 2.10 5.63 2.14 5.49 2.18 5.35 2.23
¢
Model: AOYG12KMCDN
AFR
m
3
/h
780
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 3.44 1.78 3.36 1.81 3.28 1.85 3.20 1.89 3.12 1.92
-20 -21 3.98 1.94 3.88 1.98 3.79 2.02 3.70 2.06 3.60 2.10
-15 -16 4.52 2.10 4.41 2.14 4.30 2.19 4.19 2.23 4.09 2.27
-10 -11 4.90 1.99 4.78 2.03 4.66 2.08 4.55 2.12 4.43 2.16
-5 -7 5.28 1.88 5.15 1.92 5.03 1.96 4.90 2.00 4.78 2.04
0 -2 5.66 1.78 5.53 1.81 5.39 1.85 5.26 1.89 5.12 1.93
5 3 6.04 1.67 5.90 1.70 5.75 1.74 5.61 1.77 5.47 1.81
7 6 6.20 1.63 6.05 1.66 5.90 1.69 5.75 1.73 5.61 1.76
10 8 6.20 1.55 6.05 1.58 5.90 1.61 5.75 1.64 5.61 1.67
15 10 6.20 1.47 6.05 1.50 5.90 1.53 5.75 1.56 5.61 1.59
¢
Model: AOYG14KMCDN
AFR
m
3
/h
820
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-25 -26 4.90 2.61 4.79 2.66 4.67 2.71 4.55 2.77 4.44 2.82
-20 -21 5.60 2.89 5.47 2.95 5.34 3.01 5.20 3.07 5.07 3.13
-15 -16 6.30 3.17 6.15 3.23 6.00 3.30 5.85 3.36 5.70 3.43
-10 -11 6.40 2.84 6.24 2.90 6.09 2.96 5.94 3.02 5.79 3.08
-5 -7 6.49 2.52 6.34 2.57 6.18 2.63 6.03 2.68 5.87 2.73
0 -2 6.59 2.20 6.43 2.24 6.27 2.29 6.12 2.34 5.96 2.38
5 3 6.68 1.88 6.52 1.91 6.36 1.95 6.20 1.99 6.05 2.03
7 6 6.72 1.75 6.56 1.78 6.40 1.82 6.24 1.86 6.08 1.89
10 8 6.72 1.62 6.56 1.65 6.40 1.68 6.24 1.72 6.08 1.75
15 10 6.72 1.50 6.56 1.53 6.40 1.56 6.24 1.59 6.08 1.62
- 8 -
4-2. Heating capacity 4. Capacity table
