8. External input and output
PCB External input External output Connector Input select Input signal
External input and
output
(UTY-XCSXZ2)
Operation/Stop
CN313/
CN314
Dry contact/
Apply voltage
Edge/Pulse
Forced stop
Forced thermostat off CN313 Edge
Operation status
CN310
Error status CN311
Indoor unit fan
operation status
CN312
NOTE: External input and output PCB cannot be used with Wireless LAN adapter simultaneously.
- 17 -
8. External input and output
WALL MOUNTED
ASYG09-14KMCDN
WALL MOUNTED
ASYG09-14KMCDN
