Fujitsu ASYG09KMCDN Design & Technical Manual

2. Dimensions
2-1. Models: ASYG09KMCDN, ASYG12KMCDN, and
ASYG14KMCDN
Unit: mm
(834)
Outline of indoor unit
327
273273 54
(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
- 4 -
2-1. Models: ASYG09KMCDN, ASYG12KMCDN, and ASYG14KMCDN 2. Dimensions
WALL MOUNTED ASYG09-14KMCDN WALL MOUNTED ASYG09-14KMCDN
