Fujitsu ASYG14LZCA User Manual

- 10 -
WALL MOUNTED ASYG09-14LZCA
4. Dimensions
4-1. Models: ASYG09LZCA, ASYG12LZCA, and ASYG14LZCA
Unit: mm
375
for pipe inlet Ø 65
for pipe inlet Ø 65
387
Outline of unit
470 470
270
43
295
295
940
940
387
83
77
393
40
9
43

Fujitsu ASYG14LZCA Specifications

General

Brand	Fujitsu
Model	ASYG14LZCA
Category	Air Conditioner
Language	English
