WALL MOUNTED ASYG09-14LZCA
6. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
6-1. Cooling capacity
 Model: ASYG09LZCA
 Model: ASYG12LZCA
AFR
m
3
/h
830
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10.0 2.31 2.27 0.19 2.58 2.28 0.19 2.71 2.38 0.19 2.85 2.49 0.20 2.93 2.68 0.19 3.10 2.67 0.19 3.28 2.76 0.20
-5.0 2.27 2.21 0.21 2.53 2.22 0.21 2.66 2.32 0.21 2.79 2.43 0.22 2.87 2.62 0.22 3.04 2.61 0.22 3.21 2.70 0.22
0.0 2.22 2.16 0.22 2.47 2.18 0.22 2.60 2.28 0.22 2.73 2.37 0.23 2.81 2.57 0.22 2.97 2.56 0.22 3.14 2.65 0.23
5.0 2.17 2.13 0.23 2.42 2.14 0.23 2.55 2.24 0.23 2.67 2.33 0.24 2.75 2.52 0.23 2.91 2.50 0.23 3.08 2.60 0.24
10.0 2.12 2.07 0.21 2.36 2.08 0.21 2.49 2.18 0.22 2.61 2.27 0.23 2.69 2.46 0.22 2.84 2.44 0.22 3.01 2.54 0.23
15.0 2.07 2.04 0.26 2.31 2.04 0.26 2.43 2.14 0.26 2.55 2.22 0.27 2.63 2.41 0.26 2.78 2.39 0.26 2.94 2.49 0.27
20.0 2.34 2.29 0.33 2.61 2.30 0.33 2.70 2.40 0.34 2.87 2.51 0.34 2.96 2.71 0.34 3.14 2.70 0.34 3.32 2.77 0.35
25.0 2.22 2.17 0.38 2.48 2.18 0.38 2.56 2.28 0.38 2.73 2.39 0.39 2.81 2.57 0.39 2.98 2.56 0.39 3.15 2.63 0.39
30.0 2.10 2.05 0.42 2.34 2.07 0.42 2.42 2.16 0.42 2.58 2.25 0.43 2.66 2.43 0.43 2.82 2.43 0.44 2.98 2.48 0.44
35.0 1.98 1.93 0.46 2.20 1.94 0.47 2.28 2.03 0.47 2.43 2.12 0.48 2.50 2.29 0.48 2.65 2.28 0.49 2.80 2.33 0.49
40.0 1.76 1.59 0.43 1.96 1.73 0.44 2.03 1.81 0.44 2.16 1.88 0.45 2.23 2.04 0.45 2.36 2.03 0.45 2.50 2.08 0.45
46.0 1.51 1.50 0.43 1.69 1.60 0.44 1.74 1.68 0.44 1.85 1.75 0.45 1.92 1.89 0.45 2.03 1.88 0.45 2.13 1.93 0.45
AFR
m
3
/h
830
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10.0 3.02 2.85 0.28 3.36 2.86 0.28 3.54 3.00 0.29 3.77 3.18 0.29 3.83 3.38 0.29 4.05 3.35 0.29 4.28 3.57 0.30
-5.0 2.99 2.82 0.33 3.34 2.83 0.33 3.51 2.97 0.34 3.74 3.14 0.34 3.80 3.34 0.34 4.02 3.32 0.34 4.25 3.54 0.35
0.0 2.97 2.80 0.37 3.31 2.81 0.37 3.49 2.94 0.37 3.71 3.12 0.38 3.77 3.32 0.38 3.99 3.30 0.38 4.22 3.52 0.39
5.0 2.95 2.78 0.39 3.29 2.80 0.39 3.46 2.92 0.40 3.68 3.10 0.40 3.74 3.30 0.41 3.96 3.28 0.41 4.19 3.49 0.42
10.0 2.93 2.75 0.40 3.26 2.77 0.40 3.43 2.90 0.41 3.65 3.07 0.41 3.71 3.26 0.41 3.93 3.25 0.41 4.15 3.47 0.43
15.0 2.90 2.74 0.42 3.24 2.76 0.42 3.40 2.88 0.42 3.62 3.05 0.43 3.68 3.24 0.43 3.90 3.23 0.43 4.12 3.44 0.44
20.0 3.28 3.09 0.55 3.65 3.11 0.56 3.77 3.25 0.56 4.02 3.44 0.57 4.15 3.66 0.57 4.40 3.64 0.57 4.64 3.88 0.58
25.0 3.12 2.93 0.63 3.47 2.95 0.63 3.59 3.09 0.64 3.83 3.27 0.64 3.95 3.48 0.64 4.18 3.46 0.65 4.42 3.68 0.66
30.0 2.95 2.77 0.70 3.28 2.78 0.71 3.40 2.91 0.71 3.62 3.09 0.71 3.73 3.28 0.72 3.96 3.27 0.73 4.18 3.49 0.74
35.0 2.77 2.61 0.77 3.08 2.62 0.78 3.19 2.74 0.79 3.40 2.90 0.80 3.50 3.09 0.80 3.71 3.08 0.81 3.92 3.27 0.82
40.0 2.34 2.33 0.72 2.60 2.34 0.73 2.69 2.44 0.74 2.87 2.58 0.74 2.96 2.75 0.74 3.14 2.74 0.75 3.31 2.92 0.76
46.0 1.98 1.97 0.72 2.22 2.10 0.73 2.29 2.20 0.74 2.43 2.32 0.74 2.50 2.48 0.74 2.66 2.47 0.75 2.81 2.63 0.76
