Fujitsu ASYG14LZCA User Manual

- 39 -
WALL MOUNTED AOYG09-14LZCAN
2. Dimensions
2-1. Models: AOYG09LZCAN, AOYG12LZCAN, and
AOYG14LZCAN
790
Top view
Front view
Side view
18
62
290
18
20
20
9
110
620
209
352
175
320
4-ø11.3 mm hole
540
Airflow
ø20 hole
Bottom view
(6x20=120) (6x20=120)
25
23
25 23
55
55
(
10
)
(
10
)
(
10
)
20
20
hole
17.5
25
1010
hole
102
