Fujitsu asyg18lfca Design & Technical Manual

¢
Slim duct type
Front viewSide view
1.5 m
2 m
1 m
Microphone
Measuring duct Measuring duct
Microphone
Set the static pressure
as rating in this area
¢
Mini duct type
Front viewSide view
1.5 m
2 m
1 m
Microphone
Measuring duct Measuring duct
Microphone
Set the static pressure
as rating in this area
¢
Wall mounted type
0.8 m
1 m
Microphone Microphone
NOTE:
Detailed shape of the actual indoor unit might be slightly different from the one illustrated
above.
DESIGN & TECHNICAL MANUAL
- 134 -
MULTI TYPE 5, 6 ROOMS TYPE
