16-2. Cassette grille

Lineup

Type Model

Indoor units

Compact cassette

Cassette grille UTG-UFYD-W ◌

●: Accessory, ◌: Optional, —: Not applicable

Part

Cassette grille

UTG-UFYD-W

- 265 -

MULTI TYPE

5, 6 ROOMS TYPE
