Fujitsu asyg18lfca Design & Technical Manual

6. Capacity table
6-1. Combinations
¢
Model: AOYG36LBLA5

Cooling
Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency
class
1 2 3 4 5 1 2 3 4 5
7 24 — — — 31 2.00 7.00 — — — 3.5 9.0 11.1 0.8 2.31 3.29 3.89 9.0 6.5 A++
9 24 — — — 33 2.50 7.00 — — — 3.5 9.5 11.8 0.8 2.53 3.59 3.75 9.5 6.5 A++
12 24 — — — 36 3.33 6.67 — — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.5 A++
14 24 — — — 38 3.68 6.32 — — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.5 A++
18 18 — — — 36 5.00 5.00 — — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.5 A++
18 24 — — — 42 4.29 5.71 — — — 3.5 10.0 12.5 0.8 2.79 3.88 3.58 10.0 6.4 A++
24 24 — — — 48 5.00 5.00 — — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.4 A++
7 7 14 — — 28 2.00 2.00 4.00 — — 3.5 8.0 10.0 0.8 1.90 2.85 4.21 8.0 6.7 A++
7 7 18 — — 32 2.00 2.00 5.00 — — 3.5 9.0 11.4 0.8 2.32 3.44 3.88 9.0 6.7 A++
7 7 24 — — 38 1.84 1.84 6.32 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
7 9 12 — — 28 2.00 2.50 3.50 — — 3.5 8.0 10.0 0.8 1.90 2.85 4.21 8.0 6.7 A++
7 9 14 — — 30 2.00 2.50 4.00 — — 3.5 8.5 10.7 0.8 2.10 3.15 4.05 8.5 6.7 A++
7 9 18 — — 34 2.00 2.50 5.00 — — 3.5 9.5 12.1 0.8 2.55 3.74 3.72 9.5 6.6 A++
7 9 24 — — 40 1.75 2.25 6.00 — — 3.5 10.0 12.5 0.8 2.80 3.88 3.57 10.0 6.6 A++
7 12 12 — — 31 2.00 3.50 3.50 — — 3.5 9.0 11.1 0.8 2.27 3.29 3.97 9.0 6.7 A++
7 12 14 — — 33 2.00 3.50 4.00 — — 3.5 9.5 11.8 0.8 2.50 3.59 3.80 9.5 6.7 A++
7 12 18 — — 37 1.89 3.24 4.87 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
7 12 24 — — 43 1.63 2.79 5.58 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.59 10.0 6.6 A++
7 14 14 — — 35 2.00 4.00 4.00 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
7 14 18 — — 39 1.79 3.59 4.62 — — 3.5 10.0 12.5 0.8 2.80 3.88 3.57 10.0 6.6 A++
7 14 24 — — 45 1.56 3.11 5.33 — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.5 A++
7 18 18 — — 43 1.62 4.19 4.19 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.59 10.0 6.6 A++
7 18 24 — — 49 1.43 3.67 4.90 — — 3.5 10.0 12.5 0.8 2.77 3.88 3.61 10.0 6.5 A++
9 9 9 — — 27 2.50 2.50 2.50 — — 3.5 7.5 9.6 0.8 1.74 2.70 4.30 7.5 6.7 A++
9 9 12 — — 30 2.50 2.50 3.50 — — 3.5 8.5 10.7 0.8 2.10 3.15 4.05 8.5 6.7 A++
9 9 14 — — 32 2.50 2.50 4.00 — — 3.5 9.0 11.4 0.8 2.32 3.44 3.88 9.0 6.7 A++
9 9 18 — — 36 2.50 2.50 5.00 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
9 9 24 — — 42 2.14 2.14 5.72 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.58 10.0 6.6 A++
9 12 12 — — 33 2.50 3.50 3.50 — — 3.5 9.5 11.8 0.8 2.50 3.59 3.80 9.5 6.7 A++
9 12 14 — — 35 2.50 3.50 4.00 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
9 12 18 — — 39 2.31 3.08 4.61 — — 3.5 10.0 12.5 0.8 2.80 3.88 3.57 10.0 6.6 A++
9 12 24 — — 45 2.00 2.67 5.33 — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.5 A++
9 14 14 — — 37 2.44 3.78 3.78 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
9 14 18 — — 41 2.20 3.41 4.39 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.58 10.0 6.6 A++
9 14 24 — — 47 1.91 2.98 5.11 — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.5 A++
9 18 18 — — 45 2.00 4.00 4.00 — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.5 A++
9 18 24 — — 51 1.76 3.53 4.71 — — 3.5 10.0 12.5 0.8 2.76 3.88 3.62 10.0 6.5 A++
12 12 12 — — 36 3.33 3.33 3.33 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
12 12 14 — — 38 3.16 3.16 3.68 — — 3.5 10.0 12.5 0.8 2.81 3.88 3.56 10.0 6.6 A++
12 12 18 — — 42 2.86 2.86 4.28 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.58 10.0 6.6 A++
12 12 24 — — 48 2.50 2.50 5.00 — — 3.5 10.0 12.5 0.8 2.77 3.88 3.61 10.0 6.5 A++
12 14 14 — — 40 3.00 3.50 3.50 — — 3.5 10.0 12.5 0.8 2.80 3.88 3.57 10.0 6.6 A++
12 14 18 — — 44 2.73 3.18 4.09 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.59 10.0 6.6 A++
12 14 24 — — 50 2.40 2.80 4.80 — — 3.5 10.0 12.5 0.8 2.76 3.88 3.62 10.0 6.5 A++
12 18 18 — — 48 2.50 3.75 3.75 — — 3.5 10.0 12.5 0.8 2.77 3.88 3.61 10.0 6.5 A++
12 18 24 — — 54 2.22 3.33 4.45 — — 3.5 10.0 12.5 0.8 2.75 3.88 3.64 10.0 6.5 A++
14 14 14 — — 42 3.33 3.33 3.33 — — 3.5 10.0 12.5 0.8 2.79 3.88 3.58 10.0 6.6 A++
14 14 18 — — 46 3.04 3.04 3.92 — — 3.5 10.0 12.5 0.8 2.78 3.88 3.60 10.0 6.5 A++
14 14 24 — — 52 2.69 2.69 4.62 — — 3.5 10.0 12.5 0.8 2.75 3.88 3.63 10.0 6.5 A++
14 18 18 — — 50 2.80 3.60 3.60 — — 3.5 10.0 12.5 0.8 2.76 3.88 3.62 10.0 6.5 A++
18 18 18 — — 54 3.33 3.33 3.33 — — 3.5 10.0 12.5 0.8 2.75 3.88 3.64 10.0 6.5 A++
7 7 7 7 — 28 2.00 2.00 2.00 2.00 — 3.5 8.0 10.0 0.8 1.84 2.85 4.34 8.0 6.8 A++
7 7 7 9 — 30 2.00 2.00 2.00 2.50 — 3.5 8.5 10.7 0.8 2.00 3.15 4.25 8.5 6.8 A++
7 7 7 12 — 33 2.00 2.00 2.00 3.50 — 3.5 9.5 11.8 0.8 2.32 3.59 4.10 9.5 6.8 A++
7 7 7 14 — 35 2.00 2.00 2.00 4.00 — 3.5 10.0 12.5 0.8 2.50 3.88 4.00 10.0 6.8 A++
7 7 7 18 — 39 1.79 1.79 1.79 4.63 — 3.5 10.0 12.5 0.8 2.49 3.88 4.01 10.0 6.8 A++
7 7 7 24 — 45 1.56 1.56 1.56 5.32 — 3.5 10.0 12.5 0.8 2.47 3.88 4.05 10.0 6.7 A++
7 7 9 9 — 32 2.00 2.00 2.50 2.50 — 3.5 9.0 11.4 0.8 2.17 3.44 4.15 9.0 6.8 A++
7 7 9 12 — 35 2.00 2.00 2.50 3.50 — 3.5 10.0 12.5 0.8 2.50 3.88 4.00 10.0 6.8 A++
7 7 9 14 — 37 1.89 1.89 2.43 3.79 — 3.5 10.0 12.5 0.8 2.50 3.88 4.00 10.0 6.8 A++
7 7 9 18 — 41 1.71 1.71 2.20 4.38 — 3.5 10.0 12.5 0.8 2.49 3.88 4.02 10.0 6.8 A++
7 7 9 24 — 47 1.49 1.49 1.91 5.11 — 3.5 10.0 12.5 0.8 2.46 3.88 4.06 10.0 6.7 A++
7 7 12 12 — 38 1.84 1.84 3.16 3.16 — 3.5 10.0 12.5 0.8 2.49 3.88 4.01 10.0 6.8 A++
7 7 12 14 — 40 1.75 1.75 3.00 3.50 — 3.5 10.0 12.5 0.8 2.49 3.88 4.02 10.0 6.8 A++
7 7 12 18 — 44 1.59 1.59 2.73 4.09 — 3.5 10.0 12.5 0.8 2.48 3.88 4.04 10.0 6.8 A++
7 7 12 24 — 50 1.40 1.40 2.40 4.80 — 3.5 10.0 12.5 0.8 2.46 3.88 4.07 10.0 6.7 A++
7 7 14 14 — 42 1.67 1.67 3.33 3.33 — 3.5 10.0 12.5 0.8 2.48 3.88 4.03 10.0 6.8 A++
7 7 14 18 — 46 1.52 1.52 3.04 3.92 — 3.5 10.0 12.5 0.8 2.47 3.88 4.05 10.0 6.7 A++
7 7 14 24 — 52 1.35 1.35 2.69 4.61 — 3.5 10.0 12.5 0.8 2.45 3.88 4.08 10.0 6.7 A++
7 7 18 18 — 50 1.40 1.40 3.60 3.60 — 3.5 10.0 12.5 0.8 2.46 3.88 4.07 10.0 6.7 A++
7 9 9 9 — 34 2.00 2.50 2.50 2.50 — 3.5 9.5 12.1 0.8 2.35 3.74 4.05 9.5 6.8 A++
7 9 9 12 — 37 1.89 2.43 2.43 3.25 — 3.5 10.0 12.5 0.8 2.50 3.88 4.00 10.0 6.8 A++
7 9 9 14 — 39 1.79 2.31 2.31 3.59 — 3.5 10.0 12.5 0.8 2.49 3.88 4.01 10.0 6.8 A++
7 9 9 18 — 43 1.63 2.09 2.09 4.19 — 3.5 10.0 12.5 0.8 2.48 3.88 4.03 10.0 6.8 A++
DESIGN & TECHNICAL MANUAL
- 282 -
OUTDOOR UNIT AOYG36LBLA5
