Specifications

 Controller

Unit: mm

Top view

Front view Side view

205

1761

Size (H × W × D) mm 205 × 61 × 17

Weight g 122 (without batteries)

 Holder

Unit: mm

48.5

5.5

26.2

69.3

6.5

Front View Side View

Bottom View

Ø 3.5

(Hole)

150

106.8

Hole

3.5

2-R

Size (H × W × D) mm 150 × 69.3 × 26.2

Weight g 27

- 163 -

MULTI TYPE

5, 6 ROOMS TYPE
