2. Connect the remote controller cable.

• Connect the cable made in step 1. to the indoor unit PCB.

Remote controller cable

Connecting cable

Indoor unit PCB

¢ Optional parts

Wall mounted Model name

LU UTY-TWBXF

LM UTY-XCBXZ2

The communication kit is needed for connecting the wired remote controller to the wall mount-

ed type.

DESIGN & TECHNICAL MANUAL

- 186 -

MULTI TYPE

5, 6 ROOMS TYPE
