¢ Models: ASYG07LUCA, ASYG09LUCA, ASYG12LUCA, and

ASYG14LUCA

Unit: mm

282

870 185

187: Installed state

Outline of Unit

Ø65

for pipe inlet

Ø65

for pipe inlet

DESIGN & TECHNICAL MANUAL

- 34 -

MULTI TYPE

5, 6 ROOMS TYPE
