Fujitsu AUT36ALA3W User Manual

– 27 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
OUTDOOR UNIT
Ref.
No.
Description
AOT36ACF3L AOT36RCF3L
Ord.
Q’ty
2 Fan Cover 9352159015 9352159015 9352159015 9352159015 9352159015 9352159015
4 Emblem-Rear 9351355005 9351355005 9351355005 9351355005 9351355005 9351355005
5 Cabinet-A, Painted 9352146015 9352146015 9352146015 9352146015 9352146015 9352146015
6 Cabinet-C, Painted 9352149016 9352149016 9352149016 9352149016 9352149016 9352149016
9 Cabinet-B, Painted 9352147012 9352147012 9352147012 9352147012 9352147012 9352147012
12 Base Assy, Painted 9352136016 9352136016 9352136016 9352136016 9352136016 9352136016
15 Dryer 9300589031 9353789006 9353789006 9353789006 9353789006 9353789006
16 Condenser Assy 9352128011 ––––– ––––– ––––– ––––– –––––
16-1 Condenser-A Assy ––––– 9353023001 9355338011 9355338011 9355338011 9355338011
16-2 Condenser-B Assy ––––– 9353024008 9353363008 9353363008 9353363008 9353363008
18 Suction Pipe 9352286001 9352286001 9353200006 9353200006 9358823002 9358823002
19 Capillary Tube 9352439001 ––––– ––––– ––––– ––––– –––––
19-1 Capillary Tube ––––– ––––– 9353644008 ––––– 9363760002 –––––
20 Discharge Pipe 9352288005 ––––– ––––– ––––– ––––– –––––
20 Discharge Pipe Assy ––––– 9357362007 9353620002 9357359007 9358833001 9361553002
21 Discharge Pipe-B 9352289002 9352289002 9353209009 9353209009 9358963005 –––––
21 Discharge Pipe-B Assy ––––– ––––– ––––– ––––– ––––– 9363748000
26 Compressor Cover-A 9352416002 9352416002 9353367006 9353367006 9358830000 9358830000
29 Separate Wall Assy 9355277013 9355277013 9355277013 9355277013 9358705018 9358705018
30 Blower Cover, Painted 9352151019 9352151019 9352151019 9352151019 9352151019 9352151019
32 Control Box Metal 9352134012 9352134012 9352134012 9352134012 9352134012 9352134012
34 Capacitor (Fan Motor) 9357965024 9357965024 9357965024 9357965024 9357965024 9357965024
36 Cord Holder Metal 9356934007 9356934007 9356934007 9356934007 9356934007 9356934007
39 Propeller Fan Assy 9300855013 9300855013 9300855013 9300855013 9300855013 9300855013
41 Fan Motor Assy-Out 9600266014 9600266014 9600266014 9600266014 9600266014 9600266014
45 Bracket (Motor) Assy 9352141003 9352141003 9352141003 9352141003 9352141003 9352141003
46 Compressor Assy 9352412004 9352412004 9353157003 9353157003 9358822005 9358822005
48 Bracket (Coupler) Assy 9355281010 9355281010 9355281010 9355281010 9355281010 9355281010
54 Condensing Pipe-A 9352296000 ––––– ––––– ––––– ––––– –––––
55 Special Nut M8 313252257701 313252257701 313252257701 313252257701 313252257701 313252257701
107 Rubber Seat-A 9351875039 9351875039 9351875039 9351875039 9363051001 9363051001
108 Sleeve-A 9351875046 9351875046 9351875046 9351875046 9363052008 9363052008
109 Terminal Cover 9351875053 9351875053 9351875053 9353360007 9352456022 9352456022
111 Terminal Packing 9351875060 9351875060 9351875060 9353361004 9352456039 9352456039
178-2 Capillary Holder Rubber 313394274808 313394274808 313394274808 313394274808 313394274808 313394274808
182 Clamp No. 249 ––––– 313361271505 ––––– 313361271505 ––––– 313361271505
184-1 Thermo. Spring-A ––––– 313728262708 ––––– 313728262708 ––––– 313728262708
185 Rubber Bushing 313005066051 313005066051 313005066051 313005066051 313005066051 313005066051
236 Controller PCB Assy ––––– 9703230035 ––––– 9703230028 ––––– 9703230011
272 Strainer Assy ––––– 9354139008 ––––– 9354139008 ––––– 9354139008
300 Suction Pipe-C ––––– 9352759000 ––––– ––––– ––––– –––––
320-1 Wire Clamp Metal 313483219905 ––––– 313483219905 ––––– 313483219905 –––––
327 Suction Pipe-A ––––– 9352754005 ––––– ––––– ––––– –––––
330 Inlet Pipe (Cond.)-A ––––– ––––– ––––– 9353310002 ––––– 9353310002
333 Accumulator 9350363018 9350363018 9350363018 9350363018 9350363018 9350363018
333-2 Accumulator (B) 9301942019 ––––– ––––– ––––– ––––– –––––
333-2 Accumulator Assy (B) ––––– 9362425001 9362425001 9362425001 9362425001 9362425001
334 Suction Pipe-B 9352557002 9352287008 9352287008 9352287008 9352287008 9352287008
343 Solenoid Coil ––––– 9359616108 ––––– 9359616108 ––––– 9359616108
344 4-Way Valve ––––– 9353055002 ––––– 9353532008 ––––– 9353532008
354 Pressure Switch ––––– 9355094009 ––––– 9355094009 ––––– 9355094009
361 Accumulator Support 9355351003 ––––– ––––– ––––– ––––– –––––
381 Locking Spacer ––––– 313209391506 ––––– 313209391506 ––––– 313209391506
401 Terminal-2P 9701971015 ––––– 9701971015 ––––– 9701971015 –––––
405 Clamp No. 1763 313816345304 313816345304 313816345304 313816345304 313816345304 313816345304
407 Clamp (Cable) No. 1259 313739340109 313739340109 313739340109 313739340109 313739340109 313739340109
527 Protection Net 9352163012 9352163012 9352163012 9352163012 9352163012 9352163012
549 Thermostat-Outdoor 9352426001 ––––– 9352426001 ––––– 9352426001 –––––
575 Condensing Pipe-C ––––– ––––– ––––– 9363460001 ––––– 9363460001
620 Inlet Pipe (Cond.) Assy 9355316019 9352741005 9353183002 9353183002 9353183002 9353183002
628 Locking Spacer-B ––––– 313005446558 ––––– 313005446558 ––––– 313005446558
646 Compressor Cover-B 313986355101 313986355101 9353368003 9353368003 9353368003 9353368003
678 Bracket (Thermistor) ––––– 313557406106 ––––– 313557406106 ––––– 313557406106
718 Discharge Pipe-C Assy ––––– 9363767001 ––––– 9363761009 ––––– –––––
718 Discharge Pipe-C ––––– ––––– ––––– ––––– ––––– 9359303008
734 Cabinet Top Plate 9352161018 9352161018 9352161018 9352161018 9352161018 9352161018
735 Distributor Assy ––––– 9354119000 9353187000 9353187000 9353187000 9353187000
788 Thermostat-Overheat 9354061002 ––––– 9354061002 ––––– 9354061002 –––––
790 Belt Heater 9361140011 9361140011 9361140028 9361140028 9358834008 9358834008
791 Magnetic Relay 9363277005 9363277005 9363277005 9363277005 9352552007 9363277005
Part No.
AOT45ACF3L AOT45RCF3L AOT54ABF3L AOT54RBF3L
AOT36ACF3L
AOT36RCF3L
AOT45ACF3L
AOT45RCF3L
AOT54ABF3L
AOT54RBF3L

Fujitsu AUT36ALA3W Specifications

General

Brand	Fujitsu
Model	AUT36ALA3W
Category	Air Conditioner
Language	English
