– 28 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
OUTDOOR UNIT (Continued)
Ref.
No.
Description
AOT36ACF3L AOT36RCF3L
Ord.
Q’ty
803 Cabinet-D, Painted 9352150012 9352150012 9352150012 9352150012 9352150012 9352150012
805 Blower Cover Corner 9352160011 9352160011 9352160011 9352160011 9352160011 9352160011
806 Cond. Pass Pipe-A 9352294006 ––––– ––––– ––––– ––––– –––––
806 Cond. Pass Pipe-A Assy ––––– 9355736008 ––––– ––––– ––––– –––––
807 Cond. Pass Pipe-B ––––– 9354112001 ––––– ––––– ––––– –––––
807 Cond. Pass Pipe-B Assy 9353090010 ––––– ––––– ––––– ––––– –––––
808 Inlet Pipe (Accum.) Assy 9352556005 9363464009 9352285004 ––––– 9352285004 –––––
809 Ball Valve-A 9357976006 9357976006 9357976006 9357976006 9357976006 9357976006
810 Ball Valve-B 9357982007 9357982007 9357982007 9357982007 9357982007 9357982007
812 Grip 9352157004 9352157004 9352157004 9352157004 9352157004 9352157004
813 Cabinet Hook 9352148002 9352148002 9352148002 9352148002 9352148002 9352148002
815-2 Terminal 8P 9363276022 9363276022 9363276022 9363276022 9363276022 9363276022
816 Wire Clamp Metal 313584219902 313584219902 313584219902 313584219902 313584219902 313584219902
817 Thermostat Fixture 9352164019 ––––– 9352164019 ––––– 9352164019 –––––
818 Accumulator Support-B 9355350006 ––––– ––––– ––––– ––––– –––––
819 Joint Pipe (Valve-A) ––––– ––––– 9353621009 ––––– 9353621009 –––––
819 Valve-A Coupl. Pipe 9352298004 ––––– ––––– ––––– ––––– –––––
820 Joint Pipe (Capillary) 9352299001 ––––– ––––– ––––– ––––– –––––
821 Joint Pipe (Valve-B) 9352284007 9352284007 9352284007 9353307002 9352284007 9353307002
822 Fan Cover Fixture-A 9352158018 9352158018 9352158018 9352158018 9352158018 9352158018
823-2 Fuse Holder 0500063024 ––––– 0500063024 ––––– 0500063024 –––––
824-4 Fuse 0600222529 ––––– 0600222529 ––––– 0600222529 –––––
825 Expansion Valve Assy ––––– ––––– ––––– 9363453003 ––––– 9363453003
825-1 Expansion Valve, Main ––––– 9363454017 ––––– ––––– ––––– –––––
826 Condensing Pipe-B 9352297007 ––––– 9353215000 9353215000 9353215000 9353215000
842 Cond. Pass Pipe-C ––––– 9354111004 ––––– ––––– ––––– –––––
846 Relay ––––– 9304375005 ––––– 9304375005 ––––– 9304375005
857 Inlet Pipe (Accum.)-B ––––– ––––– ––––– 9363459005 ––––– 9363459005
862 Valve-B Coupl. Pipe ––––– ––––– ––––– 9353309006 ––––– 9353309006
863 Joint Pipe (Capillary)-B ––––– ––––– 9353206008 ––––– 9353206008 –––––
880-1 Network (C-R) 9700987017 9700987017 9700987017 9700987017 9700987017 9700987017
918 Thermistor Assy ––––– 9703129025 ––––– 9703129025 ––––– 9703129025
919 Expansion Valve Coill ––––– 9363467017 ––––– 9363467017 ––––– 9363467017
Part No.
AOT45ACF3L AOT45RCF3L AOT54ABF3L AOT54RBF3L
AOT36ACF3L
AOT36RCF3L
AOT45ACF3L
AOT45RCF3L
AOT54ABF3L
AOT54RBF3L
