Mainboard D2778 Deutsch - 23
Fujitsu Technology Solutions 59
Kommunikationsanschlüsse
USB-Port (intern) – Intern/Vorderseite
POL Signal POL Signal
1 Key 2 Nicht angeschlossen
3 VCC AUX 4 VCC AUX
5 Data negative Port X 6 Data negative Port X
7 Data positive Port X 8 Data positive Port X
9 GND 10 GND
Pin 1 Pin 2
11 Key 12 Nicht angeschlossen
High Definition Audio Frontblendenanschluss (intern)
POL Signal POL Signal
1 HDA Port 1 Left 2 Analog GND
3 HDA Port 1 Right 4 FP Presence Detect
5 HDA Port 2 Left 6 Jack Sense Port 1
7 Jack Sense common 8 Key
Pin 1 Pin 2
9 HDA Port 2 Right 10 Jack Sense Port 1
Fire Wire
POL Signal POL Signal
1 TPA + 2 TPA -
3 GND 4 GND
5 TPB + 6 TPB -
7 +12V (Polyswitch gesichert) 8 + 12V (Polyswitch gesichert)
Pin 1 Pin 2
9 Key 10 GND
