Fujitsu D3031 User Manual

D3031 (RX200 S6) Technical Manual 29
Features Connectors and indicators
No. Print Description
1 CN7 Front video connector (VGA)
2 CN10 Connector for USB Flash Module (UFM)
3 CN1 PSU I
2
C connector
4 CN11 SATA1 HDD connector (4 ports)
5 CN13 PSU main connector
6 SATA2 SATA ODD connector
7 JP16 Connector for external generation of a system reset
8 CN2 Front panel connector
9JP4, JP6,
JP7, JP10,
JP11, JP12
System fan connectors
10 CN30 Connector for TPM

Fujitsu D3031 Specifications

General

Brand	Fujitsu
Model	D3031
Category	Motherboard
Language	English
