TechNotes D3162-B V1.0 Page 12 of 45 www.ts.fujitsu.com/mainboards
Feature Overview
2.5 I/O-Shield
Spring Steel Sheet
Enforcement Sheet
(front view)
Rear Side: EMI Gasket
(Foam with Aluminium)
