4 - English Interfaces and connector
s
Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The com ponents and connectors marked are not nec essarily present o n the mainboard.
External ports
The location of the external con nections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard port, pu rple PS/2 m ouse port, green
LAN port (RJ-45) Microphone jack (mono), pink
Audio input (Line in), light blue USB 2.0 – Universal Serial Bus, black
Audio output (Line out), light green USB 3.0 – Universal Serial Bus, blue
DVI – I
Serial interface, turquoise
DP DisplayPort
