Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The c om ponents an d connectors marked are not necessarily present on the mainboard.
External ports
The location of the external connections of your mainboard is specified at the b eginning of the manual.
LAN port (RJ-45)
DP DisplayPort
Audio output (HP)
Audio output (Line out)
Socket type A black: Universal Serial Bus
–USB2.0
Socket type A blue: Universal Serial B us –
USB 3.1 Gen 1
Microphone port HDMI port
