Fujitsu D3654 Series User Manual

Internal connectors and slots
HDMI
Displayport
LAN
USB 2.0 x 2
M.2 NVMe
USB 3.1 x 2
Gen1
LPD
SPKF
SATA
Battery
FAN2
FAN1
M.2 WLAN
19V DC IN
DP
(Displayport)
USB 2.0 USB 3.1
GEN 1
USB 2.0
USB 3.1
GEN 1
Power Button
USB
Drive Power
(5V only)
Mic/Head-
phone
USB 3.1 x 1
Gen 1
USB 3.1 x 1
Gen 1
USB TYP-C
Mic
Power Button
RCV/PWD Header
Front Panel
HDMI
Connector
DC IN LAN
D3654-B
D3654-B
I/O Shield Rear
D3654-B
I/O Shield Rear Front
D3654-B
Top side
Channel A, Slot 2
Channel B, Slot 1
