1. Overview
This chapter provides external views, features, specifications, and system configuration examples of the power
synchronized unit and the AC sensor unit (optional). The names and usages of the various components of the
power synchronized unit and the AC sensor unit are also described.
External View
Figure 1 and Figure 2 show the external views of the power synchronized unit and the AC sensor unit.
■ Power synchronized unit
Figure 1 External view of a power synchronized unit
■ AC sensor unit
Figure 2 External view of an AC sensor unit
