Fujitsu fi-4340C Cleaning And Maintenance

● 34
Insert the new Pick rollers with the
notch aligned with the screw. (two
rollers)
Pass the Pick shaft through the Pick
bearing, and insert the Pick shaft
into the groove of Guide A with the
bearings upright. (two shafts)
#
Notch
Screws
New Pick roller
Notch
$
Pick bearing
