29
- Locating the Controls and Connectors
Air Vents
The air vents allow air to circulate through the system to cool down the components.
Modular Bay Release Latch
The modular bay release latch is used to release the modular bay device from the modular bay.
Memory Upgrade Compartment
Your Tablet PC comes with high speed Double Data Rate 3 Synchronous Dynamic RAM (DDR3 1066
MHz SDRAM). The memory upgrade compartment allows you to expand the system memory capacity of
your Tablet PC, thus improving overall performance. See “Memory Upgrade Module” on page 90. Under
normal circumstances, it should not be necessary to open this compartment.
Port Replicator Connector
This connector allows you to connect the optional Port Replicator to your Tablet PC.
Cleanable Dust Filter
The dust filter is used to help remove dust and dirt fin your system. See “Cleaning the dust filter” on
page 125.
TO PROTECT YOUR TABLET PC FROM DAMAGE AND TO OPTIMIZE SYSTEM PERFORMANCE, BE SURE TO
KEEP ALL AIR VENTS UNOBSTRUCTED, CLEAN, AND CLEAR OF DEBRIS. THIS MAY REQUIRE PERIODIC
CLEANING, DEPENDING UPON THE ENVIRONMENT IN WHICH THE SYSTEM IS USED.
D
O NOT OPERATE THE TABLET PC IN AREAS WHERE THE AIR VENTS CAN BE OBSTRUCTED, SUCH AS IN
TIGHT ENCLOSURES OR ON SOFT SURFACES LIKE A BED OR CUSHION.
