Removing and installing components
during servicing
Installing a memory m odule
2
a
1
► Insert the memory module with the contacts
and the recess (a) facing the slot (1).
MemoryexpansionMemorymodule
► Carefully push the memory module
downwards until you feel it click
into place (2).
Attaching the c over
2
1
► Place the cover in the correct mounting position (1).
If you remove more than one component at the same time, keep the screws for the
individual components separate from each other a nd make sure that you use the correct
screws. If you install the wrong screws, components may be damaged.
► Tighten the screw (2).
Fujitsu Technology Solutions 71
