■ Function Description of BGMA
The MB2146-07-E BGMA is updated from MB2146-08-E. The updated features are described be-
low.
• BGMA power supply is DC 5V (Power supply from the USB pin)
• UART Baud rate Max speed improved:
Data in MB95260H, MB95310L, MB95370L, MB95330H, MB95390H, MB95350L,
MB95410H and MB95470H series are updated at 125kbps, data in MB95560H series is up-
dated at 500kbps and data in MB95630H and later series are updated at 1Mbps.
• Baud rate selection between 500kbps and 1Mbps (in MB95630H series and following develop
MCU)
• Clock up enable function
• RAM Monitoring Function
• 16 bytes data continuous read
• 8 bytes data continuous write
• Supply power to target board seletable
• Power supply key to control BGMA power
• LED to show BGMA operation result
• Update BGMA by connection to PCs
• Flexible operation voltage range to target MCU power supply : 1.8V*
1
to 5.5V*
2
*1 : for 3.3V power supply MCU, the voltage range is 1.8V to 3.6V
*2 : for 5V power supply MCU, the voltage range is 2.4V to 5.5V
The following shows the power supply state indicated by the BGMA LED.
Table3 Power supply indication of BGMA
The following shows the status indicated by the BGMA LED.
Table4 Status indication of BGMA
LED Status Information
Green & Red OFF Both BGMA and target board power supply off
Green ON BGMA Power supply on only
Red ON Target board power supply on only
Orange ON Both BGMA and target board power supply on
LED Status Information
Green & Red OFF Idle mode
Green
ON Standalone mode
Blinking Standalone programming, target CR trimming
Red
ON
Program (standalone, USB programmer, Trimming) error,
logging data write error
Twinkling Reserved
Orange
ON Logging will full soon
Twinkling Logging data record time is over 255 × (8kbyte-9)
