4. Interface Overview
This chapter describes the BGMA interface.
4.1 MB2146-07-E Appearance
Figure 2 shows the BGMA appearance
Figure 2 BGMA Appearance
Status LED
Mode key
Interface cable
Power supply
LED
Power supply
key
USB connector
User interface connector
