2.1 Configuring In-band Management IP setting
This section will describe how to configure the in-band management IP setting.
Beginning in privileged EXEC mode, follow these steps to configure management IP setting for
in-band management interface:
Command Purpose
Step 1 configure Enter global configuration mode.
Step 2 ip address protocol
<bootp|dhcp|none>
To set IP management interface to use
bootp, dhcp or none.
Step 3 ip address <ipaddress> <netmask>
[<vlanId>]
To set a fixed IP address and net mask for
management interface.
Step 4 exit Return to privileged EXEC mode.
Step 5 show ip interface Verify the configuration.
To configure a fixed IP address for the in-band management interface, use ip address
protocol none global configuration command. To set an IP address and net mask for
in-band management interface, use ip address global configuration command. To display
IP setting of in-band management interface, use show ip interface privileged EXEC
command.
In this example, in-band management interface is set to use IP address 192.168.2.1and
net mask 255.255.255.0. With this configuration, any untagged packets with the
destination IP of Ethernet Connection Blade will be allowed to access the Ethernet
Connection Blade.
(BX900-CB1)#configure
(BX900-CB1)(Config)#ip address protocol none
Changing protocol mode will reset ip configuration.
Are you sure you want to continue? (y/n)y
(BX900-CB1)(Config)#ip address 192.168.2.1 255.255.255.0
(BX900-CB1)(Config)#exit
(BX900-CB1)#show ip interface
IP address and netmask: 192.168.2.1 255.255.255.0,
and address mode: User specified.
InBand Mgmt Granted Ports: BX900-CB1/0/1, BX900-CB1/0/2, BX900-CB1/0/3,
BX900-CB1/0/4, BX900-CB1/0/5, BX900-CB1/0/6,
BX900-CB1/0/7, BX900-CB1/0/8, BX900-CB1/0/9,
BX900-CB1/0/10, BX900-CB1/0/11, BX900-CB1/0/12,
BX900-CB1/0/13, BX900-CB1/0/14, BX900-CB1/0/15,
