CX400
M4
Disassembly and Recycling Instructions
21
Disassembly and recycling
Figure 15: Removing the midplane kit (B)
Ê
Grip the mid
plane ki
t with the met
al bars (see circles), pull
i
t to the front (1)
and remove it out of the chassis (2).
Figure 16: Midplane kit
components
Pos.
Component
1
PSU interposer
2
Chassis interface board
3
Mid
plane
20
22
Table of Contents
Table of Contents
5
Recycling Information
7
Disassembly of the Server Enclosure
9
Removing Server Nodes from the Server Enclosure
9
Removing the ID Card and Server Cover
12
Removing the Hot-Plug PSU
16
Removing Fan Modules
17
Removing the Fan Cage
19
Removing the Midplane Kit
20
Removing 2.5-Inch HDD/SSD Modules
22
Removing 2.5-Inch HDD Backplanes
24
Removing the HDD/SSD Bridge Board
25
Removing Front Bezels
26
Removing the Front Panel Modules
28
Disassembly of the Server Nodes
30
Removing the SXM2 Extension Tray, SXM2 Modules and LC Kit
30
Removing the GPGPU Extension Tray and Gpgpus
42
Removing Riser Modules and Expansion Cards
49
Removing an FBU
54
Removing an OCP Mezzanine Card
56
Removing Main Memory Modules
57
Removing the Heat Sink and CPU (Air Cooling)
59
Removing the Heat Sink and CPU (LC)
61
Removing the Irmc Microsd Card
69
Removing M.2 Ssds
69
Removing the Dual Microsd 64GB Enterprise
70
Removing the TPM and System Board
72
Removing the Battery
76
