70 Disassembly and Recycling Instructions CX400 M4
Disassembly and recycling
Figure 93: Removing the M.2 SSD
Ê Remove the screw (see circle).
Ê Pull the M.2 SSD out of its slot (1).
Ê Remove the second M.2 SSD in the same way.
1.3.11 Removing the Dual microSD 64GB Enterprise
Tools: tool-less
Recycling parts
Dual microSD 64GB Enterprise, microSD cards
Metal
Plastic
Printed circuit
Cable
