76 Disassembly and Recycling Instructions CX400 M4
Disassembly and recycling
1.3.13 Removing the battery
Figure 102: Position of CMOS battery on system board
Figure 103: Removing the CMOS battery
Ê Press the locking spring into direction of the arrow (1), so that the CMOS
battery jumps out of its socket.
Ê Remove the CMOS battery (2).
Tools: Phillips PH1 / (+) No. 1 screw driver
Recycling parts
1x battery
Metal
1
2
