62 Disassembly and Recycling Instructions CX400 M4
Disassembly and recycling
Figure 78: Removing the memory modules LC heat sink clamps
Ê Remove the memory modules heat sink clamps (see circles).
Figure 79: Disconnecting the LC power cables
Ê Disconnect the LC power cables (1), (2).
