Fujitsu PRIMERGY RX1330 M1 User Manual

60 Operating Manual RX1330 M1
Starting up and operation
6.1.1.1 Control elements
Symbol Button Function
On / Off button
This button is used to switch the server on or off.
I If the system is running an ACPI-compliant
operating system, the pressing the On / Off
button will performs a graceful shutdown.
NMI NMI button
This button is used to troubleshoot software and
device driver errors It can be pressed using the
end of a paper clip.
V CAUTION!
Use this button only if directed to do so by
qualified certified maintenance personnel!
RST Reset button
This button is used to reboot the system. It can be
pressed using the end of a paper clip.
V CAUTION!
Risk of data loss!
ID ID button
This button highlights the ID indicator on the front
and I/O panels for easy server identification.

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
