RX1330 M1 Operating Manual 65
Starting up and operation
6.1.2 Rear of server
ID indicator and error indicator
Figure 11: Indicators on the connector panel: ID and Error indicators
1 ID and Error indicators (blue and orange)
ID ID indicator (blue on)
Lights up blue when the system has been selected by pressing
the ID button. To deactivate, press the button again.
The ID indicator can also be activated via the ServerView
Operations Manager and the iRMC S4 Web interface and its
status reported to the ServerView Operations Manager and the
iRMC S4.
blue flashing
Local monitor off
햲

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
