Fujitsu PRIMERGY RX1330 M1 User Manual

68 Operating Manual RX1330 M1
Starting up and operation
Indicator on hot-plug power supply unit
Figure 13: Indicator on hot-plug power supply unit
1 Indicator on hot-plug power supply unit (two colors)
Flashes green (1 Hz) when the server is switched off, but mains
voltage is present (standby mode).
Lights up green when the server is switched on and functioning
properly.
Flashes orange in case of an overload (>105%).
Lights up orange in the following cases:
– PSU failure
– Over voltage or under voltage
– Over temperature
– Fan failure
00

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
