RX2520 M1 Operating Manual 27
Functional overview
RAID controllers (expansion cards)
Slots
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 compliant
(option)
RAID controllers RAID 5/6 Ctrl., HDD SAS 6 Gb, LSI, 8 ports ext.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB Cache,
Optional FBU (based on LSI SAS2208).
RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1024 MB Cache,
Optional FBU (based on LSI SAS2208).
RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu, 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache,
(based on LSI SAS2108).
RAID 0/1 Ctrl., SAS/SATA 6 Gb, Fujitsu, 8 ports int.
RAID level: 0, 1, 10, No BBU support (based on LSI
SAS2008).
PCI-Express 3.0 x8 6 x low profile
PCI-Express 2.0 x4 1 x low profile
Slot notes One PCIe Gen3 x8 slot may be occupied with a
Modular RAID controller if configured.
Important: 4 PCIe x8 slots are supported with the first
processor. 7 PCIe slots are supported with two
processors.
