Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
8x3.5-inch, 12x3.5-inch for SAS/SATA, 4x 2.5-inch,
8x 2.5-inch, 12x 2.5-inch, 16x 2.5-inch for
SAS/SATA/SSD optional
Accessible drive bays 1 x 5.25/1.6-inch for backup device or
1 x 3.5/1.6-inch for backup device or
1 x 5.25/0.5-inch for ODD drive or
1 x 3.5/0.5-inch for ServerView Local Service
Display
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/off button
Reset button
NMI button
ID button
Status LEDs Global error indicator (orange)
ID indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (orange / yellow / green)
HDD/SSD error indicator (orange)
PSU error indicator (orange)
Temperature error indicator (orange)
CPU error indicator (orange)
Memory error indicator (orange)
Fan error indicator (orange)
ID indicator (blue)
CSS indicator (yellow)
