74 Operating Manual
RX2520 M1
Starting up and operation
Indicators on the hot-plug power supply unit
Figure 14: Indicator on hot-plug power supply unit (example AC power supply unit)
1 Indicator on hot-plug power supply unit (two colors)
Flashes green when the server is switched off, but voltage is present
(standby mode).
Lights up green when the server is switched on and functioning
properly.
Flashes orange in case of overload, but the power supply unit is still
running.
Lights up orange in case of PSU failure, overvoltage / undervoltage,
overtemperature, fan fail.
