Interfaces
Onboard or integrated controllers
Slots
USB connectors 7 x USB 2.0 (3x front, 2x rear, 2x internal)
Graphics (15-pin) 2 x VGA (1x front, 1x rear)
Serial (9-pin) 1 x serial RS-232-C
LAN / Ethernet (RJ-45) 2 x 10 Gbit/s Ethernet (RJ45)
2 x 10 Gbit/s Ethernet (SFP+) optional
Service LAN (RJ45) 1 x dedicated service LAN port for iRMC S4
(10/100/1000 Mbit/s) Service LAN traffic can be
switched to shared onboard Gbit LAN port
RAID Controller 8 port RAID 0/1 or RAID 5/6 controller as option
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4, 32 MB attached memory incl. graphics
controller), IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 compliant
(option)
PCI-Express Gen3 x8 8 x half length/full height
PCI-Express Gen3 x16 2 x (3/4 length/full height)
PCI-Express Gen3 x8
(for modular RAID)
1 x half length/full height
