Fujitsu PRIMERGY TX1310 M3

18 Operating Manual TX1310 M3
Functional overview
Onboard or integrated controllers
Slots
Drive bays
Operating Panel
Serial ATA total 5
RAID Controller RAID level 0, 1, 10
SATA Controller Embedded in Intel
®
Chipset C236
®
LAN Controller Single chip GbE Ethernet controller Intel
®
i219LM
onboard,
1 x 10/100/1000 Mbit/s, PXE-Boot by LAN via PXE-
Server, Teaming supported
Trusted Platform
Module (TPM)
Infineon V1.2 / V2.0 compliant (option)
PCI-Express Gen3 x16
(mechanically x8)
1x
PCI-Express Gen3 x4
(mechanically x16)
1x support for VGA adapter D3453
PCI-Express Gen3 x1 2x (both notched)
HDD bay configuration 4x 3.5-inch SATA
Accessible drives 1x 5.25-inch RDX backup drive (optional)
Optical drives 1x ultra slim ODD
Operating button On/off button
Status LEDs Power Power-on (white)
HDD access HDD activity indicator
