Fujitsu PRIMERGY TX1310 M3

TX1310 M3 Operating Manual 19
Functional overview
Dimensions / Weight
Ventilation clearance
At least 200 mm on the front and rear.
Ambient conditions
Condensation during operation must be avoided!
Noise level
Electrical values of the PSU
Floorstand (W x D x H) 179.95 x 312.9 x 373.95 mm
Weight max. 12 kg (depending on configuration)
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5 °C ... 40 °C (with ATD 40 °C)
10 °C ... 35 °C
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85% (non condensing)
Sound power level L
WAd
(ISO 9296) < 3.7 B (standby)
< 4.0 B (operation)
Sound pressure level at adjacent position
L
pAm
(ISO 9296)
< 24 dB (A) (standby)
< 24 dB (A) (operation)
Power supply configuration Standard power supply
Max. output 250 W
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Rated current max. 3.3 A – 1.3 A (100 V / 240 V)
