24 Operating Manual
TX1330 M2
Onboard or integrated controllers
Slots
Management LAN
(RJ45)
1 x dedicated Management LAN port for iRMC S4
(10/100/1000 Mbit/s). Management LAN traffic can
be switched to shared onboard Gbit LAN port
RAID Controller Modular RAID 0/1 controller with "Integrated RAID"
(SAS IR) for SAS3.0.
RAID levels 0 and 1 are supported for internal hard
disk drive configurations.
Modular RAID 0/1 controller with “MegaRAID
functionality” (SAS MegaRAID) for SAS3.0.
RAID levels 0, 1, 10, 1E, 5 and 50 are supported for
internal hard disk drive configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS3.0. RAID
levels 0, 1, 10, 1E, 5, 50, 6 and 60 are supported for
internal hard disk drive configurations.
SATA Controller A 6-port SATA controller is integrated on the system
board; up to four SATA hard disk drives can be
connected to the controller. The LSI Embedded
MegaRAID software (SATA Software RAID)
supports RAID levels 0, 1 and 10.
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / 1.2 (option)
TPM 2.0
PCI-Express Gen3 x1 1x (up to 167 mm length)
PCI-Express Gen3 x4 1x (up to 167 mm length)
PCI-Express Gen3 x8 2x (up to 240 mm length)
Slot notes In SAS configuration 1x PCI-Express occupied by
modular RAID controller.
