Fujitsu PRIMERGY TX1330 M2

TX1330 M2 Operating Manual 25
Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
4x / 8x / 12x 3.5-inch, for SAS / SATA or 8x / 16x /
24x 2.5-inch for SAS/SSD optional
Accessible drive bays 3 x 5.25/1.6-inch
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/off button
NMI button
Reset button
ID button
Status LEDs Global error indicator (orange)
ID indicator (blue)
HDD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)
CSS indicator (yellow)
Status LED at system
rear side:
Global error / CSS / ID indicator (orange / orange /
blue)
LAN connection indicator (green)
LAN speed indicator (green / yellow)
