Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel® Xeon® processor server
Page 3 / 9 www.fujitsu.com/fts
Technical details
PRIMERGY TX140 S1p
Housing types Tower Tower Tower Tower
Storage drive architecture 3.5-inch 2.5-inch 3.5-inch 2.5-inch
Power supply Standard Standard Hot-plug Hot-plug
Mainboard
Mainboard type D3049
Chipset Intel® C202
Processor quantity and type 1 x Intel® Pentium® processor / Intel® Core™ i3 processor / Intel® Xeon® processor E3-1200v2 product family
Processor Intel® Core™ i3-3220 processor
(2C/4T, 3.30 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Pentium® processor G2120
(2C/2T, 3.10 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Xeon® processor E3-1220v2
(4C/4T, 3.10 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1230v2
(4C/8T, 3.30 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1240v2
(4C/8T, 3.40 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1265Lv2
(4C/8T, 2.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 45 W)
Intel® Xeon® processor E3-1270v2
(4C/8T, 3.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1280v2
(4C/8T, 3.60 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Memory slots 4
Memory slot type DIMM (DDR3) UDIMM
Memory capacity (min. - max.) 2 GB - 32 GB
Memory protection ECC
Memory options 4 GB (1 module(s) 4 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
8 GB (1 module(s) 8 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
Memory modules notes 1600 MHz memory modules
Interfaces
USB 2.0 ports 10
Graphics (15-pin) 1 x VGA
Serial connection 1 x serial RS-232-C, usable for iRMC or system or shared
LAN / Ethernet 2 x Gb/s Ethernet
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S3 (10/100/1000 Mbit/s)
Management LAN trafc can be switched to shared onboard Gbit LAN port
Onboard or integrated Controller
RAID controller Optionally integrated RAID 0/1 or RAID 5/6 controller for SAS base units (occupies one PCIe slot).
additional RAID controller options are described under Components RAID controller
SATA Controller Intel® C200, 2 ports used for accessible drives
4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux;
LAN Controller Intel® 82574L + Intel® 82579LM onboard, 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration), iSCSI and PXE-Boot
via LAN, WoL for Intel® 82574L only.
Remote Management Controller Integrated Remote Management Controller (iRMC S3, 32 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
Trusted Platform Module (TPM) Inneon / 1.2 (option)
