Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel® Xeon® processor server
Page 4 / 9 www.fujitsu.com/fts
Slots
PCI-Express 3.0 x16 1 x
PCI-Express 2.0 x1 (mech. x4) 1 x
PCI-Express 2.0 x4 (mech. x8) 1 x
PCI-slots 1 x PCI 32/33 MHz, 1x long, 5V
Slot Notes In SAS conguration 1x PCI-Express occupied by modular RAID controller.
In congurations with Intel® Core™ i3 or Intel® Pentium® processors slots are operated with PCI-Express 2.0.
Drive bays
Storage drive bays 3.5-inch or 2.5-inch hot-plug SAS/SATA
Accessible drive bays 3 x 5.25/1.6-inch
Notes accessible drives all possible options described in relevant system congurator
Drive bays (Base unit specic)
Storage drive bays Max 4 x 3.5-inch Max 8 x 2.5-inch
Accessible drive bays 3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD 3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
General system information
Number of fans 1
Fan conguration 1 standard fan
Fan notes non redundant / non hot-plug
Operating panel
Operating buttons On/off switch
NMI button
Reset button
Status LEDs System status (orange / yellow)
Identication (blue)
Hard disks access (green)
Power (orange / green)
At system rear side:
System status (orange / yellow)
Identication (blue)
LAN connection (green)
LAN speed (green / yellow)
CSS (yellow)
BIOS
BIOS features ROM based setup utility
Recovery BIOS
BIOS settings save and restore
Local BIOS update from USB device
Online update tools for main Windows and Linux versions
Local and remote update via ServerView Update Manager
Remote PXE boot support
Remote iSCSI boot support
