TX2550
M4
Operating Manual
65
Starting up and
operation
6.2.1.3
Indicator o
n the ODD
Figure 1
1:
Example: Indicator on the ODD
I
There are also O
DDs without activity indicators.
Pos. Indicator
St
atus
Description
1
Activity
indicator
of
f
The ODD is inactive.
green on
The storage medium is
being accessed.
64
66
