9.1 Basic Specifications
1
2
No. Items Specification Remarks
1 Scanner Type ADF (Automatic Document Feeder) -
2 Image sensor CCD x 2 Front / Back
3 Light source White cold cathode fluorescent lamp x 2 Front / Back
4 Scanning
area
Minimum
A8 size (Portrait) ADF 127g/
m
2
paper
Maximum
A4 / Legal size
Long page scanning :
216 x 864mm
(8.50 x 34 in)
-
5 Paper Weight
52 g/m
2
to 127 g/m
2
(14 to 34lb)
(Note (*1))
6 Scanning
Speed (A4
Portrait)
(Note (*2))
Binary
(monochrome)
Simplex: 15 sheets/min.
Duplex: 30 sides/min.
200 dpi
Color
Simplex: 15 sheets /min.
Duplex: 30 sides/min.
150 dpi
7 Capacity of ADF 50 sheets
A4, 80 g/m
2
(20lb)
(Note (*3))
(*1) For details, see "
Chapter 7 DOCUMENT SPECIFICATIONS FOR ADF".
(*2) The scanning speed is the maximum speed of the scanner hardware. Software processing time such as
data transfer time is added to the actual scanning time.
(*3) The maximum stacking capacity varies according to the document thickness. For details, see "
Chapter 7
DOCUMENT SPECIFICATIONS FOR ADF".
