Rack console Controls
34 U41858-J-Z126-2-76
Sliding the rack console out of the rack
Ê Loosen the finger screws (1)
Ê Pull the rack console while you hold the handle (2) until it locks into place.
Opening the rack console
Ê Use the handle to push the cover of the Rack Console up until the monitor is open at
an angle of 110 degrees.
/
/
