Switching the server on and off Switching the SE700 / SE500 on and off
U41858-J-Z126-2-76 77
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.41 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k08
8.2.2 Switching the SE server on
The figure below shows the hardware involved in switching the Server Unit /390 on/off.
Figure 32: Hardware involved in switching the Server Unit /390 on/off
Detailed information on switching the hardware on/off using the SE Manager is provided in
the "Operation and Administration" manual [5].
The following hardware components must be switched on in the specified order.
1. Switch on the optional hardware components
Ê Switch on the ETERNUS LT40 S2 tape library using the On/Off switch at the front (see
the "Additive Components" Operating Manual [4]).
Ê Switch on any other connected hardware components.
USB
relay
FST access
Power on/off
USB2
Management Unit
SU /390
local console
Administration LAN
SE Server SE700 / SE500
https://<se server>
Administration PC
USB1
