121
- Introducing the Fingerprint Sensor Device
With Master Password
Once you return to a site you have remembered with OmniPass, you may be presented with a master password
prompt. Enter your master password and you will be allowed into the site.
Logging into Windows with a Fingerprint Device
When logging into Windows with a fingerprint device, the fingerprint capture window will now appear next to the
Windows Login screen. Place your enrolled fingertip on the sensor to authenticate. You will be simultaneously logged
into Windows and OmniPass. The capture window will also appear if you have used Ctrl-Alt-Del to lock a system, and
the fingerprint device can be used to log back in as stated above.
Password Management
OmniPass provides an interface that lets you manage your passwords. To access this GUI, double-click the OmniPass
key in the system tray. Click Vault Management; you will be prompted to authenticate. Once you gain access to Vault
Management, click Manage Passwords under Vault Settings. You will see the Manage Passwords interface, with a
list of friendly names.
You can view credentials stored for any remembered website by highlighting the desired resource under Password
Protected Dialog and clicking Unmask Values. Should a password be reset, or an account expire, you can remove
stored credentials from OmniPass. Highlight the desired resource under Password Protected Dialog and click Delete
Page. You will be prompted to confirm the password deletion.
The two check boxes in Manage Passwords govern whether OmniPass prompts you to authenticate or directly logs
you into the remembered site.
OmniPass will overwrite an old set of credentials for a website if you attempt to use Remember Password on an
already remembered site.
IF A MACHINE IS LOCKED AND OMNIPASS DETECTS A DIFFERENT USER LOGGING BACK IN WITH A FINGERPRINT, THE FIRST USER WILL BE LOGGED OUT
AND THE SECOND USER LOGGED IN.

Table of Contents

Other manuals for Fujitsu Stylistic Q702

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu Stylistic Q702 and is the answer not in the manual?

Fujitsu Stylistic Q702 Specifications

General IconGeneral
Form factorConvertible (Detachable)
Product typeHybrid (2-in-1)
Product colorSilver
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli3-3227U
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency1.9 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)17 W
CPU multiplier (bus/core ratio)19
Maximum number of PCI Express lanes16
GPS (satellite)Yes
Motherboard chipsetIntel® QM77 Express
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
Total storage capacity128 GB
Compatible memory cardsSD, SDHC, SDXC
Number of SSDs installed1
Display diagonal11.6 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness400 cd/m²
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Maximum resolution1920 x 1200 pixels
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Audio systemRealtek ALC269
Rear camera resolution (numeric)5 MP
3G standardsHSDPA, HSUPA, UMTS
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile network generation3G
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Keyboard layout-
Trial softwareMcAfee Internet Security
Pre-installed softwareAdobe Reader
Operating system installedWindows 8 Pro
Processor codeSR0XF
Processor ARK ID72057
Processor package size31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity3150 mAh
Battery life (max)4.12 h
Battery recharge time4.2 h
Number of battery cells3
AC adapter power60 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.16 A
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth195 mm
Width302 mm
Height12.7 mm
Weight850 g
