52
-
Docking Station Status Indicators
There are two sets of status indicators on the docking status, one on the left front edge and one on the left back
corner.
Figure 28. Docking Station Status Indicators
Docking Indicator
The docking indicator lights when the tablet is properly seated in the tablet support.
Battery Charge Indicator
The battery charge indicator shows the charging status of the keyboar
d dock battery. (See Table 1 on page 21 for
equivalent system indicator states).
